The company specialises in Comercial, Residential and Mechanical drafting.
Whether it be a basic hand drawing for a residential, commercial or industrial property, or a meeting to discuss any other type of projects we have the experience and the skill to provide an all around service to your needs.
MECHANICAL DRAFTERS SERVICES is focused on providing the highest quality drafting service to its customers all around Australia..
Our head office is based in Gold Coast.
Our management team are highly skilled and experienced coming from an international industry background. We can also credit our ongoing investment in staff training and development which has been instrumental in our success and growth to date.
Our business is structured with a hands on management approach and acknowledges the importance of industry educational training.
All team members bring a depth of knowledge to the business from the largest to small projects. Commercial & Residential all around Australia and Overseas.
Our team remains up to date with the latest industry developments while honouring our commitment to our customer's through our high level of customer service.
Residential Project
2014, NSW/Australia
DRAFTING RESIDENTIAL
2 Bedrooms / Master Bedroom / 2 Bathrooms / Theatre / Single Garage. Total 180.94 sqm.
Residential Project
2015, Qld/Australia
DRAFTING RESIDENTIALV
2 Bedrooms / Master Bedroom / 2 Bathrooms / Theatre / Double Garage. Total 182.33 sqm.
Residential Duplex
2015, Qld/Australia
DRAFTING RESIDENTIAL
2 Bedrooms / Master Bedroom / 2 Bathrooms / Single Garage - per Duplex. Total 248.36 sqm.
Residential Project
2015, NSW/Australia
DRAFTING RESIDENTIAL
3 Bedrooms / Master Bedroom / 2 Bathrooms / Theatre / Study / Double Garage. Total 257.29 sqm.
Multi-Residential Project
2014, Manila/Malasya
DRAFTING RESIDENTIAL
6 Floors Proyect. Total 1250 sqm.
Residential Skillion Project
2015, NSW/Australia
DRAFTING RESIDENTIAL
3 Bedrooms / Master Bedroom / 2 Bathrooms / Theatre / Double Garage. Total 191.43 sqm.
Residential Duplex
2015, Qld/Australia
DRAFTING RESIDENTIAL
Main Unit - 3 Bedrooms / Master Bedroom / 2 Bathrooms / Single Garage - Aux Unit - 2 Bedroom / Bathroom / Single Garage. Total 245.40 sqm.
Residential Project
2015, Victoria/Australia
DRAFTING RESIDENTIAL
3 Bedrooms / Activity / Master Bedroom / 2 Bathrooms / Theatre / Double Garage. Total 260.38 sqm.
Double Storey Residential Project
2015, Qld/Australia
DRAFTING RESIDENTIAL
5 Bedrooms / Retreat / Master Bedroom / 4 Bathrooms / Theatre / Lounge / Office / Double Garage. Total 329.35 sqm.
Residential Project
2015, Qld/Australia
DRAFTING RESIDENTIAL
2 Bedrooms / Retreat / Lounge / Master Bedroom / 2 Bathrooms / Theatre /4 Garages. Total 258.50 sqm.
Residential Duplex
2015, Qld/Australia
DRAFTING RESIDENTIAL
Main Unit - 3 Bedrooms / Master Bedroom / 2 Bathrooms / Double Garage - Aux Unit - 2 Bedroom / Master Bedroom / 2 Bathroom / Single Garage. Total 333.17 sqm.
Residential Projects
2012, Segovia/Spain
DRAFTING RESIDENTIAL
4 Bedrooms / Master Bedroom / 2 Bathrooms / Double Garages. Total 241.53 sqm.
Industrial HVAC
2014, Qld/Australia
MEP
Mechanical Drafting for air conditioning and sanitary compartment ventilation systems upper floor plan.
Commercial HVAC
2015, NSW/Australia
MEP
Mechanical Drafting for air conditioning and sanitary compartment ventilation systems upper floor plan.
Commercial HVAC
2015, Qld/Australia
MEP
Mechanical Drafting for air conditioning and sanitary compartment ventilation systems upper floor plan
Title Page
Working Drawing
Working Drawing
Site Plan
Setback, CUT & FILL, Pad level, Driveway Detail
Working Drawing
Ground Floor Plan
Floor Areas, Sections, Callout
Working Drawing
Floor Plans
Roof Plan, Penetration Plan, Concrete Setout Plan, Brick Seout Plan
Working Drawing
Building Elevations
Front, Right, Back & Left Elevations
Working Drawing
Building Sections
Building Sections, Doors & Windows Schedule
Working Drawing
Electrical Plan
Electrical Plan & Electrical Legends
Working Drawing
Bracing Plan
Bracing Plan & Bracing Direction
Working Drawing
Interior Elevations
Interior Plans & Elevations
Working Drawing
TYP Details
Brick, Eaves, Windows, Doors, Pavilion & Wall Details
Working Drawing
Title Page
Preliminary Drawing
Preliminary Drawing
Site Plan
Setback, Pad level, Driveway Detail
Preliminary Drawing
Art Impression
3D Modelling Views
Preliminary Drawing
Floor Plans
Floor Plan, Project Area
Preliminary Drawing
Building Elevations
Front, Right, Back & Left Elevations
Preliminary Drawing
Electrical Plan
Electrical Plan & Electrical Legends
Preliminary Drawing
Interior Commercial Rendering
2014
Rendering
Architecture and Interior Design.
Interior Residential Rendering
2014
Rendering
Interior Design.
Exterior Residential Rendering
2015
Rendering
Interior Design.
Interior Commercial Rendering
2014
Rendering
Interior Design.
Exterior Residential Rendering
2015
Rendering
Interior Design.
Interior Commercial Rendering
2015
Rendering
Interior Design.
Interior Commercial Rendering
2015
Rendering
Interior Design.
Exterior Residential Rendering
2015
Rendering
Interior Design.
Aerial Rendering
2015
Rendering
Interior Design.
Interior Commercial Rendering
2015
Rendering
Interior Design.
Residential Floor Plan Service
Start Marketing your Property to Potential Clients from the First Click on your Web Site
Residential Floor Plan Service
Commercial Floor Plan Service
Start Marketing your Property to P0tential Clients from the First Click on your Web Site
Commercial Floor Plan Service
Site Meansuring
2014, Best & Less, Robina Town Centre/Gold Coast/Australia
Site Meansuring
Site meansuring for Best and Less store in Robina Town Center. Air conditioning and ventilation systems floor plan.
Site Meansuring
2014, Soul Shopping Centre/Gold Coast/Australia
Site Meansuring
Site meansuring in Soul Shopping Centre. Air conditioning,ventilation systems and fire detection -floor plan.
Site Meansuring
2014, Soul Shopping Centre/Gold Coast/Australia
Site Meansuring
Site meansuring in Soul Shopping Centre. Air conditioning,ventilation systems and fire detection -floor plan.
Technical Details
Structural Details & Layher System
Technical Details
Mobile Launcher Patform, Looping Bike.
Technical Details
Cooling Tower Details
Technical Details
3D Induced Cooling Tower Components. Legs, Basin, Frame, Inlet Legs, Box, Condenser, Spray System, Anti Splash, Motor, 4 Blade and Cilinder.3D Condenser-Fluid Cooler, 4 Blade fan, Water Pump.
